SUPERSEAL 1.0 CONNECTOR PERFORMANCE SPECIFICATIONS
Current: Up to 15 amps
Temperature: Operating at temperatures -40°C to +125°C
Durability: After cap housing is connected, the plug housing is mated and then 78.4 N force is applied

               in a rocking motion. 25 test cycles.
Insulation Resistance: 100 megohms minimum. Test between adjacent contacts and between contact

                                and earth with insulation resistance meter of 500 volts DC.
Immersion: Per JIS D0203
Random Vibration: Tested in each of three mutually perpendicular axis.
                            See Fig 8 in product document 108-78140.
Dielectric Withstanding Voltage: Insulation does not breakdown at 1000 volts AC or 1600 volts DC for
                                              duration of 1 minute between contacts and between contact and earth.
Voltage: 250 volts AC, DC
MATERIAL SPECIFICATIONS
Grommet: Silicone rubber
Housing: Thermoplastic
TPA: Thermoplastic polyester
